Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Delivery Time: Peak Season Lead Time: 1-3 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Model NO.: |
STG-AB1536-3.5 |
Glass Edging Machine Type: |
No |
Grinding Head Number: |
No |
Condition: |
New |
After-sales Service: |
One Year |
Transport Package: |
Protective Film |
Trademark: |
Fssida |
Origin: |
China |
HS Code: |
8464201000 |
Supply Ability: |
100sets/Month |
Warranty: |
One Year |
Type: |
No |
Certification: |
CE |
Structure: |
Horizontal |
Control System: |
PLC |
Glass Washing Machine Type: |
No |
Customization: |
Available | Customized Request |
Model NO.: |
STG-AB1536-3.5 |
Glass Edging Machine Type: |
No |
Grinding Head Number: |
No |
Condition: |
New |
After-sales Service: |
One Year |
Transport Package: |
Protective Film |
Trademark: |
Fssida |
Origin: |
China |
HS Code: |
8464201000 |
Supply Ability: |
100sets/Month |
Warranty: |
One Year |
Type: |
No |
Certification: |
CE |
Structure: |
Horizontal |
Control System: |
PLC |
Glass Washing Machine Type: |
No |
Customization: |
Available | Customized Request |
| Model | STG-AB1536-35(Full quenching) | |
| Flat Glass | Max loading area | 1500 x 3600mm |
| Min Glass size | 400x300mm | |
| Glass thickness range | 3.5-12MM(Full quenching) | |
| Max glass size | 1500 x 3600MM | |
| Bend Glass | Max glass size | 1500 x 3600MM | |
| Glass thickness | 3.5-12MM | ||
| The Min. Radius. | 700MM | ||
| Bend adjustment system | Bend adjustment by special type of Hydraulic system,for high accuracy bending. | ||
| Parameter for Hydraulic | 11KW,21Mpa | ||
| Heating methods | Radiation | ||
| Requested glass quality | A No visible bubbles, impurities; A Meet the national standards of high quality float glass; > Glass shall be beveling, edging, washing and dry; | ||
| Power | Heating | 318KW | |
| Bend and fast pass area | 280KW | ||
| Cooling | 90KW | ||
| Transportation. | 6KW | ||
| Recommended transformer capacity | >315KVA | ||
| Blower Control | controlled by frequency inverters | ||
| Quality Standard | ANSI Z97.1-2004, | ||
| Finished product rate | >98% | ||
| Installation period (approximately,) | 15 working days | ||
| Commissioning period (approximately) | 10 working days | ||
| Training period (approximately) | 10 working days | ||
| Guarantee period | ONE year for non worn-out parts and components. | ||
| Power supplier mode | 220 V + 60 HZ 3phase | ||
| Glass thickness (mm) | Glass tempered cycle. (Load/hour) | Note | |
| FLAT GLASS | 3.8 | 18-22 | The size, producing area and color of glass panel will cause the production difference. The production of glass plate with small size and deep color will be slightly larger. |
| 5 | 16-18 | ||
| 6 | 14-16 | ||
| 8 | 10-12 | ||
| 10 | 9-10 | ||
| 12 | 7-8 | ||
| BEND GLASS | 3.8 | 40-45 PCS/Hour | |
| |
