Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Delivery Time: Peak Season Lead Time: 1-3 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Model NO.: |
ST-RD1000 |
Glass Edging Machine Type: |
Grinding Machine |
Grinding Head Number: |
2 |
Condition: |
New |
After-sales Service: |
Provide |
Mechanical Text Report: |
Provide |
Voltage: |
Customizable |
Certificate: |
CE |
Video Factory Inspection: |
Provide |
Color Design: |
Customized |
Processing Thickness: |
3-19mm |
Weight: |
650kg |
Power: |
7kw |
Glass Size: |
360-1000mm |
Transport Package: |
Seaworthy Package |
Specification: |
2400*1000*1550mm |
Trademark: |
FSSIDA |
Origin: |
China |
HS Code: |
8464201000 |
Supply Ability: |
30sets/Month |
Warranty: |
1 Year |
Type: |
Glass Edging Machine |
Certification: |
CE, ISO, FDA, UR, PCI, PDA |
Structure: |
Vertical |
Control System: |
PLC |
Glass Washing Machine Type: |
No |
Customization: |
Available | Customized Request |
Model NO.: |
ST-RD1000 |
Glass Edging Machine Type: |
Grinding Machine |
Grinding Head Number: |
2 |
Condition: |
New |
After-sales Service: |
Provide |
Mechanical Text Report: |
Provide |
Voltage: |
Customizable |
Certificate: |
CE |
Video Factory Inspection: |
Provide |
Color Design: |
Customized |
Processing Thickness: |
3-19mm |
Weight: |
650kg |
Power: |
7kw |
Glass Size: |
360-1000mm |
Transport Package: |
Seaworthy Package |
Specification: |
2400*1000*1550mm |
Trademark: |
FSSIDA |
Origin: |
China |
HS Code: |
8464201000 |
Supply Ability: |
30sets/Month |
Warranty: |
1 Year |
Type: |
Glass Edging Machine |
Certification: |
CE, ISO, FDA, UR, PCI, PDA |
Structure: |
Vertical |
Control System: |
PLC |
Glass Washing Machine Type: |
No |
Customization: |
Available | Customized Request |
| Body | Steel fuselage structure, annealed |
| Water tank | Standard 201 stainless steel |
| Linear screw/rail | Taiwan TBI |
| Spindle | Choose the waterproof and most stable running Hunan Jinlong custom grinding head motor |
| Working table | The working table is processed with high precision by the grinding machine to ensure the flatness of the machine table and prevent the glass from breaking due to the huge pressure of the cylinder |
| Pneumatic components | Zhejiang first-line brand: Shangde Pneumatic |
| Electrical components | Relays, AC contactors, power switches, voltage regulators and other electrical appliances use Chint first-line brands |
| Electric wire | Guangdong Pearl River Tour |
| System | Shenzhen R & D company independently tailor-made, easy to operate, good polishing effect |
| Controller | Delta system |
| Processing size | R angle processing: R5*R30/R5-R60 (two options) |
| Speed | On average, it can reach 5-8/sec for one R20 corner processing. |
| processing thickness | 3-19mm |
| Glass size | 360-1000mm |
| Motor power | 3kw× 2 |
| Weight | 650kg |
| Power | 7kw |
| Size | 2400*1000*1550mm |
| High speed opening and closing | 750KW |
| Max.processing size | 1000*1000mm |
| Min.processing size | 360*180mm |
| Air pressure | 5-6kg |
| Glass width | 400-1000mm |
nExhibition
1. who are we?
We are based in Guangdong, China, start from 2011,sell to South America(30.00%),Southeast Asia(20.00%),Mid East(15.00%),Eastern Europe(10.00%),Africa(10.00%),North America(10.00%),Western Europe(3.00%),Eastern Asia(2.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Glass Machine,Glass Furnace,Glass Bending Furnace,Glass Bending And Tempering Furnace,Glass Machines
4. why should you buy from us not from other suppliers?
Our company has a professional R & D team and a strict quality management system. 10 years of export experience. Mature after-sales installation team.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,DDP;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Arabic,French,Russian
