Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Delivery Time: Peak Season Lead Time: 1-3 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Model NO.: |
ST9325E |
Glass Edging Machine Type: |
Glass Straight Edging Machine |
Grinding Head Number: |
9 |
Condition: |
New |
After-sales Service: |
1 |
Color: |
To Order |
Electrical Parts: |
Big Brand |
Transport Package: |
Protective Film |
Trademark: |
FSSIDA |
Origin: |
China |
HS Code: |
8464201000 |
Supply Ability: |
30sets/Month |
Warranty: |
1 |
Type: |
Insulating Glass Production Line |
Certification: |
CE |
Structure: |
Vertical |
Control System: |
No |
Glass Washing Machine Type: |
No |
Customization: |
Available | Customized Request |
Model NO.: |
ST9325E |
Glass Edging Machine Type: |
Glass Straight Edging Machine |
Grinding Head Number: |
9 |
Condition: |
New |
After-sales Service: |
1 |
Color: |
To Order |
Electrical Parts: |
Big Brand |
Transport Package: |
Protective Film |
Trademark: |
FSSIDA |
Origin: |
China |
HS Code: |
8464201000 |
Supply Ability: |
30sets/Month |
Warranty: |
1 |
Type: |
Insulating Glass Production Line |
Certification: |
CE |
Structure: |
Vertical |
Control System: |
No |
Glass Washing Machine Type: |
No |
Customization: |
Available | Customized Request |
| Wheels | 9 |
| working speed | 0.6-6.0m/min |
| Max. arris width | 2.5mm |
| Min. glass size: | 60mm |
| Glass thickness | 3-20mm |
| Total power | 18.75kw |
| Total dimension | 6.6x1.0x2.6m |
| Total weight | 2800kg |
| 1#:Diamond wheel 150*12*8*8 100# | 2#:Diamond wheel 150*12*8*8 240# | 3#:Resin wheel 130*12*15*10 240# |
| 4#:Polishing wheel 130*60*35 | 5#:Resin wheel 130*12*15*12 240# | 6#:Polishing wheel 130*60*35 |
| 7#:Resin wheel 150*12*15*10 240# | 8#:Polishing wheel 150*70*40 | 9#:Polishing wheel 150*70*35 |
| Name | Description | Quantity | Brand |
| Front and rear platen | Special stretch black film, more durable and wearable | Front:98 pcs Rear:96 pcs | LOBSTER |
| Rubber pads | special stretchy rubber | ||
| Chain | good tensile strength | 4 set | DONGHUA |
| Waterproof brush | High elasticity and high temperature resistant wire | ||
| Motor P2/2.2 KW | For flat bottom glass grind | 4 set | CDQC |
| Motor High and low speed P4/1.5-2.2KW | The last motor for flat bottom glass grind | 1 set | CDQC |
| Motor P2/2.2 KW | For glass chamfering grind | 2 set | CDQC |
| Motor P2/2.2 KW | For glass chamfering grind | 2 set | CDQC |
| Variator speed control motor P4/2.2 KW | For the whole machine transmission | 1 set | XL-motor |
| Glass thickness drive Motor P4/0.25 KW | For the glass thickness adjustment | 1 set | |
| Water pump motor0.25 KW | For water circulation from water tank | 1 set | |
| Control transformer | 1 set | CHNT | |
| Thermal relay | 12 pcs | CHNT | |
| A.C. contactor | 12 pcs | CHNT | |
| On-off button | 12 pcs | CHTBO | |
| Water tank | 1 pcs |
