Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Delivery Time: Peak Season Lead Time: 1-3 months Off Season Lead Time: within 15 workdays
Payment Terms: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Model NO.: |
ST-QX2000 |
Condition: |
New |
After-sales Service: |
Remotely Guided Installation |
Glass Thickness: |
3mm-25mm |
Max Glass Size: |
2000mm |
Min Glass Size: |
400 Mm/Times |
Working Speed: |
0-10 M/Min |
Total Power: |
23kw |
Total Weight: |
4120kg |
Parts: |
Air Box |
Transport Package: |
Protective Film |
Specification: |
5000*3000*2700mm |
Trademark: |
Fssida |
Origin: |
Foshan |
HS Code: |
8464901900 |
Supply Ability: |
2 Sets/Mouth |
Warranty: |
One Year |
Type: |
Glass Washing And Drying Machine |
Certification: |
CE |
Structure: |
Horizontal |
Control System: |
Industrial Computer |
Glass Washing Machine Type: |
Horizontal Glass Washing Machine |
Customization: |
Available | Customized Request |
Model NO.: |
ST-QX2000 |
Condition: |
New |
After-sales Service: |
Remotely Guided Installation |
Glass Thickness: |
3mm-25mm |
Max Glass Size: |
2000mm |
Min Glass Size: |
400 Mm/Times |
Working Speed: |
0-10 M/Min |
Total Power: |
23kw |
Total Weight: |
4120kg |
Parts: |
Air Box |
Transport Package: |
Protective Film |
Specification: |
5000*3000*2700mm |
Trademark: |
Fssida |
Origin: |
Foshan |
HS Code: |
8464901900 |
Supply Ability: |
2 Sets/Mouth |
Warranty: |
One Year |
Type: |
Glass Washing And Drying Machine |
Certification: |
CE |
Structure: |
Horizontal |
Control System: |
Industrial Computer |
Glass Washing Machine Type: |
Horizontal Glass Washing Machine |
Customization: |
Available | Customized Request |
Stracture
Workship of glass washing machine
Air box
| Item | QX2000 |
| The maximum glass width | 2000 mm(width) |
| The minimum glass size | 400mm×400mm |
| Glass thickness range | 3mm-25mm digital readout |
| Roller brush | 3 pair |
Working speed | Thickness of glass is less than 5mm, Vmax= 7m/min Thickness of glass is 8mm to 12mm, V<= 3m/min Thickness of glass is 15mm-19mm, V= 2m/min |
| Way for changing speed of main drive: | variable frequency speed control; |
| Working table height | 880mm |
| Total power | 25kw |
| External dimension | 5000*3000*2700 |
| Weight | 3350kg |
| Glass thickness | 3-25mm |
Company profile
1. One year guarantee for the machine,except the consumable parts.
2. 24 hours technical support by e-mail/Online chatting app.
3. English control page, manual and detailed operation Videos.
