| Work piece Detail | Design Basis |
| Work piece character | Flat glass |
| Work piece size& weight | (4000mm)(L)x(2000mm)(W)x(8+8mm)(H),Max weight about 800kg |
| Handling way | Vertical/Horizontal displacement handling |
| Operating circumstance | Outside handling, Demand no less than 6 kg air source and need crane hoisting equipment. |
| Max overhang"L" | According to 16 mm thick piecework, The biggest overhang quantity "L" should be less than or equal to 1170 mm |
| | |
| Project content | Performance indicators |
| Rated load | 800kg glass can horizontal & vertical displacement handling (under the condition of 60% vacuum pressure) |
| Safety factor | 4 times,passed ISO9001 system testify:2008; Comply with European CE safety regulations |
| Safety alarm | System vacuum pressure lower than 60%, can be observed through numerical meter about pressure values |
| Pressure holding time | Cut off air supply, the time required is greater than or equal to 10 min. Of system vacuum pressure drop by the supreme to 60% |
| Suction & Release Control | Two position & three links manually slide valve |
| Noise index | Less than 60dB(A) |
| Lifting part's weight | 70kg(similar) |
| S/N | Description | P/N | Supplier | unit | Quantity |
| 1 | Vacuum ejector | max. vacuum pressure 85% | SMC(Japan) | PCS | 1 |
| 2 | Vacuum gauge | Ф63mm | ACUTEX(America ) | PCS | 1 |
| 3 | Vacuum suction pad | Ф300mm,suction100kgf(import rubber) | AEROLIFT(Germany) | SET | 4 |
| 4 | Vacuum filter | G 1/2" | Germany tech. | PCS | 1 |
| 5 | Vacuum non-return valve | G 1/2" | Germany tech. | PCS | 1 |
6 | Manual slide valve | G 1/2",Two position & three links(safety lock to prevent wrong operation) | Germany tech. | PCS | 1 |
| 7 | Manual ball valve | G 1/4",each suction cup can turn on/off separately | Germany tech. | PCS | 4 |
| 8 | Control box | Dedicated | FREDDIE | PCS | 1 |
| 9 | Vacuum suction cup buffer holder | Dedicated | FREDDIE | SET | 4 |
| 10 | Hand shank | The integrated control unit | FREDDIE | PCS | 1 |
| 11 | Vacuum safety tank | Girder integrated unit | FREDDIE | PCS | 1 |
| 12 | Steel column | (height)4.2M | FREDDIE | SET | 1 |
| 13 | Steel KBK cantilever | Dedicated | FREDDIE | SET | 1 |
| 14 | Lift cylinder | 1.3M route | SNS(Taiwan) | PCS | 1 |
| 15 | Tilter + rotation cylinder | 0-90 lifter & 0-90 rotation | SNS(Taiwan) | PCS | 1 |
